J10 Vehicle GPS Tracker With Light Sensor

The J10 is a miniaturized 2G vehicle GPS tracker integrating advanced positioning technology and intelligent sensors. Its core design philosophy is to provide a highly reliable, easy-to-install, and cost-effective asset tracking and security management solution. The product features an ultra-wide 9-90V input voltage range and innovatively incorporates a light sensor, making it suitable not only for traditional gasoline vehicles but also perfectly compatible with motorcycles, electric vehicles, and next-generation electric vehicles. The J10 is an ideal choice for fleet management, remote insurance information processing, auto finance risk control, and personal vehicle anti-theft.

1. Comprehensive Positioning and Communication Performance

Multi-mode Satellite Positioning: Utilizes the AT6558R chipset, simultaneously receiving GPS, BeiDou, and GLONASS satellite signals, and supports AGPS assisted positioning technology, significantly improving positioning speed and accuracy.

Fast Positioning Capability:

Cold Start Time: Average 32 seconds

Warm Start Time: Average 15 seconds

High Tracking Sensitivity: -160dBm, ensuring stable positioning in complex urban environments.

Stable 2G Communication: Based on the RDA 8955L GSM chip, supporting four bands (850/900/1800/1900MHz), using TCP protocol for data transmission, ensuring excellent network stability (sensitivity up to -107dBm) and reliable data upload.

2. Intelligent Security and Status Monitoring

Built-in Light Sensor: A core security feature. When the device is illegally removed from the vehicle or exposed to light, an alarm is immediately triggered, effectively countering device disassembly and vehicle theft.

Multiple Intelligent Alarm Mechanisms:

Power Failure Alarm: When the vehicle's main power is detected to be cut off, the built-in 55mAh backup battery activates, and the device immediately reports a power failure alarm.

Vibration and Displacement Alarm: Detects abnormal vibrations or illegal movement using a 3D accelerometer.

Overspeed Alarm: The platform sets a speed threshold; automatically reporting when speeding occurs.

Driving Behavior Analysis: Monitors and reports unsafe driving behaviors such as rapid acceleration, rapid deceleration, and sharp turns in real time.

Remote Power-Off Control: Authorized users can remotely cut off fuel/power to the vehicle via platform or SMS commands for emergency situations or financial risk control scenarios.

3. Industrial-Grade Design and Data Management

Ultra-Wide Voltage Input: Supports DC 9-90V, allowing direct connection to the vehicle battery without an additional voltage regulator module, compatible with various vehicle types from 12V motorcycles to 24V trucks.

Low Power Consumption Design: Operating current is 330mA, standby current is as low as 3mA, minimizing battery drain when the vehicle is stationary.

Blind Spot Data Compensation: Built-in high-capacity flash memory can store up to 1000 positioning logs. In areas without signal (such as underground parking garages), the device continuously records data and immediately retransmits it once the signal is restored, ensuring complete trajectory.

Intelligent Working Mode: Features automatic switching between static and dynamic modes. It enters a low-power static mode when the vehicle is stationary; upon detecting vibration, it immediately wakes up and switches to dynamic mode, achieving a balance between energy saving and performance.

4. Application Scenarios

Ride-hailing and taxi services: Real-time vehicle location monitoring, driver behavior management, and ensuring operational safety.

Corporate commercial fleets: Optimizing fleet routes, monitoring driving habits, and reducing operating costs and accident rates.

Auto finance and leasing: Used for asset tracking, remote vehicle locking, and mitigating default risks.

Personal vehicle anti-theft: Especially suitable for motorcycles and electric vehicles, providing multiple anti-theft protections through displacement, light, and vibration alarms.

Freight transportation security: Monitoring transportation routes to ensure cargo safety.

The J10 GPS tracker, with its industrial-grade wide-voltage design, unique physical security (light sensor), and comprehensive vehicle status and driving behavior monitoring capabilities, offers excellent cost-effectiveness and reliability in the 2G product category. It is not just a locator, but a comprehensive asset management terminal integrating intelligent early warning and remote control, effectively meeting the core needs of commercial and personal users for vehicle security and efficient management.
